Azbil C7G User Manual

6-33
Chapter 6. Display and Setting Data

PP (position proportional) bank
Bank selection: PP (POSITION PROPORTIONAL)
Loop selection: None
Group selection: None
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Output type Output type 0: Output OFF
1: MV of loop 1
2: MV of loop 2
3 to 10: Reserved
11: Heat MV of loop
1 (for heating/
cooling control)
12: Heat MV of loop
1 (for heating/
cooling control)
13: Heat MV of loop
2 (for heating/
cooling control)
14: Heat MV of loop
2 (for heating/
cooling control)
15 to 2047
: Reserved
2048 to 3071
: Standard
numerical codes
14 - 2 Standard Bit
Codes and Standard
Numerical Codes
(p.14-6)
1
# *

Selection of
control method
Control method
selection
0: MFB control +
estimated position
control
1: MFB control + close
upon line break
2: Estimated position
control
3: Estimated position
control + position
adjustment at
power-on
0

-

Dead zone Dead zone 0.5000 to 25.000 % 10.000

-

With decimal point
