Chapter 6. Display and Setting Data
The operations performed by "Write" in the "Communication" column of the table are as follows.
RAM: Data is only written to RAM. Data is not retained in the event of power failure.
EEPROM: Data is written to both RAM and EEPROM. Data is retained in the event of power failure.
Meanings of the symbols in the "Communication" column of the table are as follows.
: Possible with decimal point position settings 0 to 4
*: Possible with decimal point position settings 10 to 14
#: Possible with decimal point position settings 0 to 4 and 10 to 14
-: Not possible
Decimal point position settings 10 to 14 specify RAM access. The value after subtracting 10 is the number of
decimal places.

Monitor (RAM)/Loop1 to 4
Item Settings
Communication
Notes
Read
Write
RAM EEPROM
Loop1: (RAM) RUN/READY 0: RUN, 1: READY
 
-
Loop1: (RAM) AUTO/MANUAL 0: AUTO, 1: MANUAL
 
-
Loop1: (RAM) LSP/RSP 0: LSP, 1: RSP
 
-
Loop1: (RAM) Current LSP −32000 to +32000
 
- With decimal
point
Loop1: (RAM) Current proportional band 0.1 to 3200 %
 
-
Loop1: (RAM) Current integral time 0 to 32000 s
 
-
Loop1: (RAM) Current derivative time 0 to 32000 s
 
-
Loop1: (RAM) Current manual reset -10 to +110 %
 
-
Loop1: (RAM) Current MV low limit -10 to +110 %
 
-
Loop1: (RAM) Current MV high limit -10 to +110 %
 
-
Loop1: (RAM) Current proportional band for cooling 0.1 to 3200 %
 
-
Loop1: (RAM) Current integral time for cooling 0 to 32000 s
 
-
Loop1: (RAM) Current derivative time for cooling 0 to 32000 s
 
-
Loop1: (RAM) Current MV low limit for cooling -10 to +110 %
 
-
Loop1: (RAM) Current MV high limit for cooling -10 to +110 %
 
-
Note: The items for loops 2 to 4 are the same as those for loop 1.

Monitor/Mode
Item Settings
Communication
Notes
Read
Write
RAM EEPROM
Loop1: RUN/READY 0: RUN, 1: READY

-

Loop1: AUTO/MANUAL 0: AUTO, 1: MANUAL

-

Loop1: LSP/RSP 0: LSP, 1: RSP

-

Loop1: AT stop/start 0: AT stop, 1: AT start
 
-
Note: The items for loops 2 to 4 are the same as those for loop 1.
6 - 4 Parameter Data for Communication
