Azbil C7G User Manual

14-7
Chapter 14. Appendix
Standard
bit code
Meaning of standard bit code
1461 Result of logical operation 22
1462 Result of logical operation 23
1463 Result of logical operation 24
1464 Result of logical operation 25
1465 Result of logical operation 26
1466 Result of logical operation 27
1467 Result of logical operation 28
1468 Result of logical operation 29
1469 Result of logical operation 30
1470 Result of logical operation 31
1471 Result of logical operation 32
1504 CDS running
1505 Loop 1 health index running
1506 Loop 2 health index running
1507 Loop 3 health index running
1508 Loop 4 health index running
1517 Display unit connection status
1518 Additional display unit
connection status
1568 Loop 1 RUN/READY status
1569 Loop 2 RUN/READY status
1570 Loop 3 RUN/READY status
1571 Loop 4 RUN/READY status
1584 Loop 1 Auto/Manual status
1585 Loop 2 Auto/Manual status
1586 Loop 3 Auto/Manual status
1587 Loop 4 Auto/Manual status
1600 Loop 1 AT stop/start status
1601 Loop 2 AT stop/start status
1602 Loop 3 AT stop/start status
1603 Loop 4 AT stop/start status
1608 Loop 1 AT abnormal end
1609 Loop 2 AT abnormal end
1610 Loop 3 AT abnormal end
1611 Loop 4 AT abnormal end
1616 Loop 1 LSP/RSP status
1617 Loop 2 LSP/RSP status
1618 Loop 3 LSP/RSP status
1619 Loop 4 LSP/RSP status
1648 Loop 1 SP ramp-up in progress
1649 Loop 2 SP ramp-up in progress
1650 Loop 3 SP ramp-up in progress
1651 Loop 4 SP ramp-up in progress
1652 Loop 1 SP ramp-down in
progress
1653 Loop 2 SP ramp-down in
progress
1654 Loop 3 SP ramp-down in
progress
1655 Loop 4 SP ramp-down in
progress
1670 Enforcing loop 1 pattern SP
increase change limit
Standard
bit code
Meaning of standard bit code
1671 Enforcing loop 2 pattern SP
increase change limit
1672 Enforcing loop 3 pattern SP
increase change limit
1673 Enforcing loop 4 pattern SP
increase change limit
1674 Enforcing loop 1 pattern SP
decrease change limit
1675 Enforcing loop 2 pattern SP
decrease change limit
1676 Enforcing loop 3 pattern SP
decrease change limit
1677 Enforcing loop 4 pattern SP
decrease change limit
1712 Loop 1 pattern operation mode
1713 Loop 2 pattern operation mode
1714 Loop 3 pattern operation mode
1715 Loop 4 pattern operation mode
1720 Loop 1 HOLD state
1721 Loop 2 HOLD state
1722 Loop 3 HOLD state
1723 Loop 4 HOLD state
1728 Loop 1 END state
1729 Loop 2 END state
1730 Loop 3 END state
1731 Loop 4 END state
1736 Loop 1 G.SOAK state
1737 Loop 2 G.SOAK state
1738 Loop 3 G.SOAK state
1739 Loop 4 G.SOAK state
1792 Alarm (logical OR of all displayed
alarms)
1824 Loop 1 PV low limit error
1825 Loop 1 PV high limit error
1826 Loop 1 RSP low limit error
1827 Loop 1 RSP high limit error
1828 Loop 2 PV low limit error
1829 Loop 2 PV high limit error
1830 Loop 2 RSP low limit error
1831 Loop 2 RSP high limit error
1832 Loop 3 PV low limit error
1833 Loop 3 PV high limit error
1834 Loop 3 RSP low limit error
1835 Loop 3 RSP high limit error
1836 Loop 4 PV low limit error
1837 Loop 4 PV high limit error
1838 Loop 4 RSP low limit error
1839 Loop 4 RSP high limit error
1880 MFB input error
1884 Adjusting MFB
1888 Estimating MFB
1896 MFB adjustment error
1900 Motor drive output OPEN
Standard
bit code
Meaning of standard bit code
1904 Motor drive output CLOSE
1920 Reception monitoring 1
1921 Reception monitoring 2
1922 Reception monitoring 3
1940 User-defined alarm 1
1941 User-defined alarm 2
1942 User-defined alarm 3
1943 User-defined alarm 4
1952 CT/VT input error (block A2 CT)
1953 CT/VT input error (block A2 VT)
1954 CT/VT input error (block B2 CT)
1955 CT/VT input error (block B2 VT)
1956 CT/VT input error (block A1 CT)
1957 CT/VT input error (block A1 VT)
1958 CT/VT input error (block B1 CT)
1959 CT/VT input error (block B1 VT)
1960 CT/CT input error (block A2 CT1)
1961 CT/CT input error (block A2 CT2)
1962 CT/CT input error (block B2 CT1)
1963 CT/CT input error (block B2 CT2)
1964 CT/CT input error (block A1 CT1)
1965 CT/CT input error (block A1 CT2)
1966 CT/CT input error (block B1 CT1)
1967 CT/CT input error (block B1 CT2)
1973 Memory error
1977 Battery error (CLOCK block)
1991 Block error
1992 SD card error
2000 Block alarm IO failure (block A1)
2001 Block alarm IO failure (block A2)
2002 Block alarm IO failure (block A3)
2003 Block alarm IO failure (block A4)
2004 Block alarm IO failure (block B1)
2005 Block alarm IO failure (block B2)
2006 Block alarm IO failure (block B3)
2007 Block alarm IO failure (block B4)
2008 Block alarm HMI block failure
2009
Block alarm SUB2 block failure
(RS-485)
2010 Block alarm SUB1 block failure
(DI DO)
2011 Block alarm MAIN block failure
