6-23
Chapter 6. Display and Setting Data
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Input type Input type 0: Always OFF
1: Always ON
2 to 10: Undefined
11: DI1
12: DI2
13:DI3
14: DI4
15: DI5
16: DI6
17: DI7
18 to 1023: Undefined
1024 to 2047: Standard bits
14 - 2 Standard Bit Codes
and Standard Numerical
Codes (p.14-6)
0
# *

The status of DI
block terminals
is included in the
standard bit codes.
Loop definition Loop definition When the operation type is
other than timer stop/start
selection,
0: All loops
1: Loop 1
2: Loop 2
3: Loop 3
4: Loop 4
When the operation type is
timer stop/start selection,
0: All timer events
1 to 16: Event number for timer
event
When the operation type is
Linearization table group
selection,
1: Block A2
2: Block B2
3: Block A1
4: Block B1
(effective only when the block
type is AO-C or V-P)
0
# *

Handling Precautions
• If the version of the MAIN block firmware is earlier than 6.x.x (where x stands
for any number), DI groups 9 to 32 are not available.
