Azbil C7G User Manual

4-51
Chapter 4. Functions
Item (bank) Display Description Initial value
Input type of DI groups 1
to 32
(DI bank)
MENU > DI
Input type
0: Always OFF
1: Always ON
2 to 10: Reserved
11: DI1
12: DI2
13: DI3
14: DI4
15: DI5
16: DI6
17: DI7
18 to 1023: Reserved
1024 to 2047: Standard bits
14 - 2 Standard Bit Codes and Standard
Numerical Codes (p.14-6)
0
Loop definition of DI groups
1 to 32
(DI bank)
MENU > DI
Loop definition
When the operation type is not
Linearization table group selection or Timer
stop/start selection,
0: All loops collectively
1: Loop 1
2: Loop 2
3: Loop 3
4: Loop 4
When the operation type is timer stop/start
selection,
0: All timer events
1 to 16: Event number for timer event
When the operation type is Linearization
table group selection,
1: Block A2
2: Block B2
3: Block A1
4: Block B1
(effective only when the block type is AO-C
or V-P)
0
Handling Precautions
• For the operation type "1 to 3: LSP group selection," the LSP group number
is determined by adding 1 to the sum of the weights (+1, +2, +4) of the DIs
that are set to ON. However, if the number of LSP system groups is exceeded,
the LSP group number that can be selected is the same as the number of LSP
groups.
• For the operation type "4 to 6: PID group selection," the PID group number is
determined by adding 1 to the sum of the weights (+1, +2, +4) of the DIs that
are set to ON. However, if the number exceeds 8, then PID group 8 is selected.
• For the "Fixed value output selection" operation type, the fixed value output
number is the sum of the weights (+1, +2, +4) of the DIs that are set to ON.
However, when the number is "0," the fixed value output is not executed. If the
number exceeds 8, the fixed value output 8 is selected.
