4-52
Chapter 4. Functions
• For the "Linearization table group selection" operation type, the group
number is the value obtained by adding the sum of the weights (+1, +2, +4) of
the DIs that are set to ON to the setting value of the linearization table group
definition. However, if the number exceeds 8, then Group 8 is selected. The
target blocks are the AO-C block and V-P block.
• For the operation type "41: Control operation direct/reverse selection," direct/
reverse is not selected if the control operation of the control bank is set to "PID
control heating/cooling action."
• For the DI to be set as the input type, set it to DI in the DI/DO configuration
bank.
4 - 10 DO (Digital Output) (p.4-65)
• If the version of the MAIN block firmware is earlier than 6.x.x (where x stands
for any number), the number of DI groups is 1 to 8, and operation is not
performed when operation type setting is 11–13, 15–17, 51–53, 61–63, 66–67,
or 70–74.
