4-53
Chapter 4. Functions
The table below shows the operations for each operation type.
Set value Operation type Operation at OFF Operation at ON
0 No function Not available Not available
1 LSP group selection (0/+1) LSP number: +0 LSP number: +1
2 LSP group selection (0/+2) LSP number: +0 LSP number: +2
3 LSP group selection (0/+4) LSP number: +0 LSP number: +4
4 PID group selection (0/+1) PID group number: +0 PID group number: +1
5 PID group selection (0/+2) PID group number: +0 PID group number: +2
6 PID group selection (0/+4) PID group number: +0 PID group number: +4
7 Reserved Not available Not available
8 PV Hold Without hold With hold
9 and 10 Reserved Not available Not available
11 Fixed value output selection (0/+1) Fixed value output group number:
+0
Fixed value output group number:
+1
12 Fixed value output selection (0/+2) Fixed value output group number:
+0
Fixed value output group number:
+2
13 Fixed value output selection (0/+4) Fixed value output group number:
+0
Fixed value output group number:
+4
14 Reserved Not available Not available
15 Output linearization table group
number selection: (0/+1)
Output linearization table group
number: +0
Output linearization table group
number: +1
16 Output linearization table group
number selection: (0/+2)
Output linearization table group
number: +0
Output linearization table group
number: +2
17 Output linearization table group
number selection: (0/+4)
Output linearization table group
number: +0
Output linearization table group
number: +4
18–20 Reserved Not available Not available
21 RUN/READY mode selection RUN READY
22 AUTO/MANUAL mode selection AUTO MANUAL
23 LSP/RSP mode selection LSP RSP
24 AT stop/start selection AT stop AT start
(The rising edge from OFF to ON
is valid.)
25 to 40 Reserved Not available Not available
41 Control operation direct/reverse
selection
Direct/reverse operation set by the
control operation of the control
bank
Reverse operation of the direct/
reverse operation set by the
control operation of the control
bank
42 to 45 Reserved Not available Not available
46 Timer stop/start selection Timer stop Timer start
47–50 Reserved Not available Not available
51 RUN/READY mode selection (edge) RUN (the falling edge from ON to
OFF is valid)
READY (the rising edge from OFF
to ON is valid)
52 AUTO/MANUAL mode selection
(edge)
AUTO (the falling edge from ON to
OFF is valid)
MANUAL (the rising edge from OFF
to ON is valid)
53 LSP/RSP mode selection (edge) LSP (the falling edge from ON to
OFF is valid)
RSP (the rising edge from OFF to
ON is valid)
54–59 Reserved Not available Not available
60 Constant value operation / pattern
operation mode selection
Constant value operation Pattern operation
61 ADVANCE (edge) None ADVANCE (the rising edge from
OFF to ON is valid)
