6-10
Chapter 6. Display and Setting Data
Item display Item Settings Initial value
Communication
Notes
Read
Write
RAM
EEPROM
No. of decimal
places for PV2
No. of decimal places
for PV2
0: No decimal point
1: 1 digit after the
decimal point
2: 2 digits after the
decimal point
3: 3 digits after the
decimal point
4: 4 digits after the
decimal point
1
- - -
Applies to the PV
and SP for loop
2 on the monitor
screen.
No. of decimal
places for PV3
No. of decimal places
for PV3
0: No decimal point
1: 1 digit after the
decimal point
2: 2 digits after the
decimal point
3: 3 digits after the
decimal point
4: 4 digits after the
decimal point
1
- - -
Applies to the PV
and SP for loop
3 on the monitor
screen.
No. of decimal
places for PV4
No. of decimal places
for PV4
0: No decimal point
1: 1 digit after the
decimal point
2: 2 digits after the
decimal point
3: 3 digits after the
decimal point
4: 4 digits after the
decimal point
1
- - -
Applies to the PV
and SP for loop
4 on the monitor
screen.
Display loop for
A2 slot input
A2 slot input value
display loop definition
0: Not displayed
1: Loop 1
2: Loop 2
3: Loop 3
4: Loop 4
1
- - -
Display loop for
B2 slot input
B2 slot input value
display loop definition
0: Not displayed
1: Loop 1
2: Loop 2
3: Loop 3
4: Loop 4
2
- - -
Display loop for
A1 slot input
A1 slot input value
display loop definition
0: Not displayed
1: Loop 1
2: Loop 2
3: Loop 3
4: Loop 4
3
- - -
Display loop for
B1 slot input
B1 slot input value
display loop definition
0: Not displayed
1: Loop 1
2: Loop 2
3: Loop 3
4: Loop 4
4
- - -
