6-43
Chapter 6. Display and Setting Data

Loop 4
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM EEPROM
PV assignment PV assignment 2048 to 3071: Standard
numerical codes
2315
# *

2315 is "PV (block
B3)."
RSP assignment RSP assignment 2048 to 3071: Standard
numerical codes
2048
# *

2048 is "fixed to 0.0."
Assignment range low
limit
Assignment
range low limit
−32000 to +32000 0.0000
# *

With decimal point
Assignment range high
limit
Assignment
range high limit
−32000 to +32000 1000.0
# *

With decimal point
Handling Precautions
• If the advanced loop type setting is enabled for [Loop type], the input
assignment bank can be displayed and set. The loop type can be set by the
SLP-C7 Smart Loader Package.
• For PV assignment and RSP assignment, the standard numerical codes are
set. In addition to the PV of the AI block, the PVs and RSPs of other loops, as
well as virtual AIs, can be assigned. Although PVs of unimplemented blocks or
invalid numerical values can also be assigned, operation will not be performed
correctly.
• If the PV and RSP are lower than the alarm setting low limit or higher than the
alarm setting high limit, an alarm is generated.
• PID calculation uses the difference between the range low limit for the
proportional band and range high limit for the proportional band as 100 % of
the proportional band.
• If the version of the MAIN block firmware is earlier than 6.x.x (where x stands
for any number), there is no input assignment bank.
