Azbil C7G User Manual

6-45
Chapter 6. Display and Setting Data
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Linearization table
group
Linearization
table group
definition
0: No linearization
1 to 8
0
# *


Virtual AI 4
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM EEPROM
Virtual AI assignment Virtual AI
assignment
2048 to 3071: Standard
numerical codes
14 - 2 Standard Bit
Codes and Standard
Numerical Codes
(p.14-6)
2114
# *

2114 is "User-
defined number 4."
Filter Filter 0.0000 to 120.00 0.0000
# *

With decimal point
Ratio Ratio 0.0010 to 10.000 1.0000
# *

With decimal point
Bias Bias −32000 to +32000 0.0000
# *

With decimal point
Linearization table
group
Linearization
table group
definition
0: No linearization
1 to 8
0
# *

Handling Precautions
• If the advanced loop type setting is enabled for [Loop type], the virtual analog
input bank can be displayed and set. The loop type can be set by the SLP-C7
Smart Loader Package.
• If the version of the MAIN block firmware is earlier than 6.x.x (where x stands
for any number), there is no virtual analog input bank.
