Azbil C7G User Manual

6-14
Chapter 6. Display and Setting Data
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Fixed value
output 7
Fixed value output 7 -10.000 to +110.00 % 0.0000
# *

With decimal point
Fixed value
output 8
Fixed value output 8 -10.000 to +110.00 % 0.0000
# *

With decimal point
Handling Precautions
• When “Control action” is changed from an action other than the PID control
heating and cooling action to PID control heating and cooling action, “PID
initial MV” and “Preset MANUAL value” are reset to 50.000 %.
• When “Control action” is changed from PID control heating and cooling action
to an action other than the PID control heating and cooling action, “PID initial
MV” and “Preset MANUAL value” are reset to 0.0000 %.
• If the version of the MAIN block firmware is earlier than 6.x.x (where x stands
for any number), "Fixed value output 1 to 8" do not exist.
