Azbil C7G User Manual

6-13
Chapter 6. Display and Setting Data
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Preset MANUAL
value
Preset MANUAL value -10.000 to +110.00 % 0.0000
# *

When the mode
is MANUAL mode
at power ON, the
preset MANUAL
value is used as the
MV.
With decimal point
MV increase
change limit
MV increase change
limit
0.0000: No limit
0.0001 to 10000 %/s
0.0000
# *

With decimal point
MV decrease
change limit
MV decrease change
limit
0.0000: No limit
0.0001 to 10000 %/s
0.0000
# *

With decimal point
MV low limit
during AT
MV low limit during AT -10.000 to +110.00 % 0.0000
# *

With decimal point
MV high limit
during AT
MV high limit during
AT
-10.000 to +110.00 % 100.00
# *

With decimal point
SP lag factor SP lag factor 0.0000 to 1000.0 0.0000
# *

With decimal point
READY MV READY MV -10.000 to +110.00 % 0.0000
# *

When the control
action is changed,
the setting may be
automatically reset
to 0.0000 or 50.000.
For details, see
Handling
Precautions
p.6-14..
With decimal point
READY MV (Heat) Output at READY
(Heat)
-10.000 to +110.00 % 0.0000
# *

Enabled when the
control action is
PID control heating
and cooling action.
With decimal point
READY MV (Cool) Output at READY
(Cool)
-10.000 to +110.00 % 0.0000
# *

MV action if PV
is bad
MV action if PV is bad 0: Continue control
operation
1: Output MV if PV is
abnormal
0
# *

MV if PV is bad MV if PV is bad -10.000 to +110.00 % 0.0000
# *

Enabled when "MV
action if PV is bad"
is 1.
With decimal point
Fixed value
output 1
Fixed value output 1 -10.000 to +110.00 % 0.0000
# *

With decimal point
Fixed value
output 2
Fixed value output 2 -10.000 to +110.00 % 0.0000
# *

With decimal point
Fixed value
output 3
Fixed value output 3 -10.000 to +110.00 % 0.0000
# *

With decimal point
Fixed value
output 4
Fixed value output 4 -10.000 to +110.00 % 0.0000
# *

With decimal point
Fixed value
output 5
Fixed value output 5 -10.000 to +110.00 % 0.0000
# *

With decimal point
Fixed value
output 6
Fixed value output 6 -10.000 to +110.00 % 0.0000
# *

With decimal point
