Chapter 14. Appendix
Description User's Manual Reference User's Manual Change
Support for clock function
1 - 2 Model No.
Model Selection Guide (p.1-2)
Slots B1 and B2: Added L, P
5 - 2 Parameter screen
Date and Time (p.5-50)
Added the content at left
4 - 19 CDS (Compact Data Storage)
Files (p.4-107),
Setting the date and time by the SLP-C7
(p.4-113)
Added a precaution for the
model Nos. “With clock function”
to the “Handling Precautions”
6 - 2 Parameter Setting Display Data
Date and time bank (p.6-41)
Added the content at left
Support for heating/cooling control
4 - 4 Control
Functional block diagram of heating/
cooling control (p.4-20)
Added the content at left
4 - 4 Control
Control action (p.4-20)
Special control output (p.4-23),
PID control (p.4-25)
Changed “2: Reserved” in the set
values of “Control action” to “2:
PID control heating and cooling
action”
Added “Output at READY (Heat),”
“Output at READY (Cool),”
“Proportional band for cool
side,” “Integral time for cool side,”
“Derivative time for cool side,”
“Output low limit for cool side,”
and “Output high limit for cool
side” items
4 - 5 AT (Auto-tuning) (p.4-28)
Added a description of AT for
heat/cool control to “Handling
Precautions”
4 - 11 TP (Time Proportioning) Output
TP output type (p.4-69)
Increased the set value range of
“TP operation types”
4 - 12 Analog Output (AO)
Output type (p.4-75)
Changed “2 to 3: Reserved” in the
set values of “Output types” to
“2: Heat MV (for heating/cooling
control)” and “3: Cool MV (for
heating/cooling control)”
6 - 1 Operation Display Data
1-loop monitor screen (p.6-2)
Added Variable display 2
Changed previous Variable
displays 2 and 3 to 3 and 4
6 - 2 Parameter Setting Display Data
PID bank (p.6-7)
Added “Proportional band
for cooling,” “Integral time for
cooling,” “Derivative time for
cooling,” “Output low limit for
cooling,” and “Output high limit
for cooling” items
6 - 2 Parameter Setting Display Data
CONTROL bank (p.6-12)
Added “Heating/Cooling control
dead zone,” “Output at READY
(Heat),” and “Output at READY
(Cool)” items.
6 - 2 Parameter Setting Display Data
ANALOG OUTPUT bank (p.6-16),
Changed “2 to 3: Reserved” in the
set values of “Output types” to
“2: Heat MV (for heating/cooling
control)” and “3: Cool MV (for
heating/cooling control)”
6 - 2 Parameter Setting Display Data
TP (time proportioning) bank (p.6-24)
Increased the set value range of
“TP output types”
