Chapter 14. Appendix
Description User's Manual Reference User's Manual Change
Added logical operation functions
4 - 18 Logical Operations
Added the content at left
6 - 2 Parameter Setting Display Data
Logical operation bank (p.6-27)
Added the content at left
Added user-defined bits
14 - 2 Standard Bit Codes and
Standard Numerical Codes
Standard bit codes (p.14-6)
The standard bit codes include
numbers corresponding to user-
defined bits 1 to 16.
6 - 2 Parameter Setting Display Data
User-defined bit bank (p.6-28)
Added the content at left
Added standard bits
14 - 2 Standard Bit Codes and
Standard Numerical Codes
Standard bit codes (p.14-6)
Added the content at left
Added PID group selection to the
operation types of DI (digital input)
Added standard bits to the input types of
DI (digital input)
4 - 8 DI (Digital Input)
DI assignment (p.4-50)
Changed “4 to 20: Undefined”
in the set values of “Operation
types” to “4 to 6: PID group
selection, 7 to 20: Undefined”
Increased the set value range of
“Input types”
6 - 2 Parameter Setting Display Data
DI bank (p.6-22)
Same as above
Added standard bits to the output types
for DO (digital output)
4 - 10 DO (Digital Output)
DO assignment (p.4-66)
Increased the set value range of
“Output types”
6 - 1 Operation Display Data
DO configuration bank (p.6-20)
Same as above
Added standard bits to the operation
types of the health index
4 - 20 Health Index
Settings (p.4-116)
Increased the set value range of
“Operation types”
6 - 2 Parameter Setting Display Data
HEALTH INDEX graph (p.6-41)
Same as above
Added ON-delay and OFF-delay to event
output
4 - 9 Events
Function block diagram
Added an “ON-delay and OFF-
delay” block
4 - 9 Events
Event main setting, event subsetting,
hysteresis, delay (p.4-64)
Added “ON-delay time” and “OFF-
delay time” items
6 - 2 Parameter Setting Display Data
EVENT bank (p.6-7)
Added “ON-delay” and “OFF-
delay” items
Added “19 (Event 9) to 26 (Event 16)
and 1024 to 2047 (Standard bits)” to the
operation types of the CDS
4 - 19 CDS (Compact Data Storage)
Recording cycle/operation type
(p.4-102)
Increased the set value range of
“Operation types”
6 - 2 Parameter Setting Display Data
CDS bank (p.6-38)
Same as above
Support for complete data notification in
the PLC link function
10 - 3 List of PLC Link Settings
Transfer settings (p.10-12)
Changed the content of
“Handling Precautions”
