10.2.4 Certified Sensors
See Table 14 for a list and description of the Certified sensors available through Dynon.
Table 14: Certified Sensors
Sensor Type
Qty
Dynon
Avionics P/N
Description
Amps Shunt
1
503101-000
0–100 Amps, 1mV=1A
Pressure – Fuel
1
503389-000*
1/8-27 NPT, Kavlico 0–50 PSI Fluid Pressure
503850-000
1/8-27 NPT, Kavlico 15 PSI Fluid Pressure
503983-000
1/8-27 NPT, Kavlico 50 PSI Fluid Pressure
503851-000
1/8-27 NPT, Kavlico 150 PSI Fluid Pressure
Pressure – Manifold
1
503387-000
0"–60" hg, 1/8" hose
Pressure – Oil
1
503388-000*
1/8-27 NPT, Kavlico 0–150 PSI Fluid Pressure
503851-000
1/8-27 NPT, Kavlico 150 PSI Fluid Pressure
Temp – CHT
4
503382-000
Type J (CHT) Thermocouple, Adjustable Bayonet
3/8-24 UNF
Temp – EGT
4
503384-000
Type K (EGT) Thermocouple, 1.00"–2.25" Hose
Clamp
Temp – Oil
1
503385-000
5/8-18 UNF, 100°F – 240°F
Temp – Carb Air
1
503416-000
1/4-28 UNF, -50°F – 150°F
* As of 2020, Dynon Avionics no longer supplies the 0-50 PSI Kavlico sensor (P/N
503389-000) and 0-150 PSI Kavlico sensor (P/N 503388-000). See Section 10.2.11 and
Section 10.2.13 for more information.
10.2.5 Tools and Equipment Required
The following list contains commonly used tools and equipment, however some of the
tools or equipment listed below may not apply to your installation:
• Wire strippers.
• 22 AWG wire.
• DSUB pin crimper.
• Faston/ring terminal crimp tool.
o Available – http://bandcspecialty.com – (316) 283-8000 – part number
RCT-1.
• Weather Pack crimp tool (common slip joint pliers will also work).
