1 Introduction
Upon receipt of your airplane’s LRUs, mouting brackets, cable harnesses, and any other
accessories, visually inspect shipping containers and (after unpacking) all components
for evidence of damage that may have occurred during shipping. If damage has occured,
contact Dynon Support.
This manual provides information about the mechanical, electrical, and pneumatic
installation and configuration of the following SkyView major system components into
aircraft listed in STC SA02594SE for approved models listed in AML SA02594SE_AML.
Autopilot installation and SkyView screen configurations are model(s) specific and are
documented in a separate documents. Not all functionality is approved for all models. The
AML specifies what aspects of the SkyView HDX System, which includes the D10A, can
be installed into a particular model of airplane.
In addition to the information provided in this installation manual, it is the installer’s
responsibility to conform to industry standards, as applicable.
This manual deals with setting up installation-dependent software options. If you have not
purchased all of the components mentioned above, you only need to read through the
sections of this manual relevant to your setup.
When a SkyView system is connected to products not manufactured or provided by
Dynon Avionics (such as NAV radios and GPS receivers), it is often necessary to refer to
those product’s technical/installation manuals/guides to configure their settings and their
wiring to be compatible with your SkyView system. While this manual provides some
information about some popular products not manufactured by Dynon Avionics, the
information provided in this manual is not comprehensive. For any third-party products
that are intend to be connect to the SkyView system, the installer should obtain the full
technical/installation manuals/guides available, for reference.
Dynon Avionics’ products incorporate a variety of precise, sensitive electronics. SkyView
products do not contain any field/user-serviceable parts such as fuses. Units found to
have been taken apart may not be eligible for repair under warranty. Additionally, once a
Dynon Avionics unit has been opened, it is not considered airworthy and must be serviced
at the factory.
1.1 Product Registration
Please take a moment to register your Dynon Avionics SkyView HDX system at
http://register.dynonavionics.com. Registering your product with Dynon Avionics ensures
that your contact information is up-to-date. This helps verify product ownership, can
expedite warranty claims, and allows us to notify you in the event a Service Bulletin is
published for your product. You can also sign up to receive other Dynon Avionics news
and product announcements. Dynon Avionics will not share your contact information with
third parties or send you announcements without your explicit consent.
