System Overview
2-14 SkyView HDX System Installation Manual - Revision E
2.9 Specifications
Table 3 contains SkyView displays and devices that are powered by SkyView displays.
5A circuit protection is recommended for SkyView displays in common configurations; as
5A is the smallest circuit breaker that is commonly available in certified versions.
Table 3: Power Specifications for SkyView Displays and Devices Powered by SkyView Network
SkyView Displays:
No SV-BAT-320 (see below)
No SkyView Network modules (see
below)
No USB devices
Display brightness at maximum
Current
requirement
@ 12V DC
Current
requirement
@ 24V DC
Circuit
Protection
Recommen-
dation
SV-HDX800 all S/N
2.10A
1.00A
5A
SV-HDX1100 all S/N
2.40A
1.20A
5A
Devices powered from SkyView Displays
These devices are directly connected to an individual SkyView display and are powered by the
display. Add the current consumption of these devices to the current consumption of the
SkyView display they are connected to. This will allow you to calculate the total current that
each SkyView display requires.
SV-BAT-320 (while charging)
1.00A
0.50A
N/A
SV-GPS-2020
0.10A
0.05A
N/A
Video Adapter for SkyView (USB)
0.15A
0.08A
N/A
SkyView Wi-Fi Adapter (USB)
0.10A
0.05A
N/A
Devices powered via SkyView Network
These devices are connected to SkyView Network, which is powered by the SkyView display(s).
If you have two (2) or three (3) displays, the current requirements of these devices are shared
equally between the displays. If you have one (1) display, add 100% of a SkyView Network
device’s current to the display’s current requirement. If you have two (2) displays, add 50% of
SkyView Network device’s current to each display’s current requirement. If you have three (3)
displays, add 33% of SkyView Network device’s current to each display’s current requirement.
SV-ADAHRS-200
0.15A
0.08A
N/A
SV-AP-PANEL (not including trim motor
loads)
0.05A
0.03A
N/A
SV-ARINC-429
0.10A
0.05A
N/A
SV-EMS-220 (maximum number of
sensors)
0.11A
0.06A
N/A
SV-KNOB-PANEL
0.07A
0.04A
N/A
SV-MAG-236
0.15A
0.08A
N/A
`For example, a SV-D1000T @ 12V with:
1 – SV-BAT-320 (1.00A),
1 – SV-GPS-2020 (0.10A),
1 – SV-ADAHRS-200 (0.15A), and
1 – SV-EMS-220 (0.11A),
