Display Operation
SkyView HDX System Installation Manual - Revision E 21-15
21.6.10 TRANSPONDER SETUP Menu
This menu is not accessible unless a SV-XPNDR-261 is setup and configured.
Reference the SV-XPNDR-261 Transponder Installation and Configuration
Section of this manual for more information.
This menu contains options that are used to set up and configure the SV-XPNDR-261
module.
21.6.11 HARDWARE CALIBRATION Menu
This menu contains links to the following menus:
• ADAHRS CALIBRATION – Enter this menu to make altitude adjustments (e.g.,
baro and altitude offset) and access the compass and AOA calibration wizards.
• EMS CALIBRATION – Enter this menu for EMS sensor calibration. You will
have options to calibrate fuel tanks and position potentiometers that have been
mapped in the Sensor Input Mapping Wizard. Calibration wizards contain
onscreen instructions.
• AP SERVO CALIBRATION – Enter this menu for autopilot servo calibration.
Reference the Section of this manual for more details.
• TRIM MOTOR CONFIGURATION – Enter this menu to configure one (1) or
two (2) trim motors (connected to / powered by the Dynon Avionics SV-AP-
PANEL 15-pin connector) for automatic trim control (Autopilot Auto-trim) during
AP operation. Reference Section 16 of this manual for more details.
Note that if ADAHRS, EMS, or Servos are not present on the SkyView
network, this menu will note the absence by displaying “(EMS NOT
DETECTED)”, “(ADAHRS NOT DETECTED)”, or “(SERVOS NOT
INSTALLED).”
21.7 Software Updates and File Operations
Dynon Avionics continually provides new functionality and capabilities to your SkyView
system via Software updates. Use the resources mentioned in the Contact Information
Section of this document to stay current on Software availability for SkyView.
The airplane owner/operater can install preventative software updates, but only an FAA-
credentialed mechanic or facility can install non-preventitive software updates. Software
updates are installed using a USB flash drive. See www.dynoncertified.com/software-
updates.php for more information.
USB Flash Drive Considerations
A 4 GB or 8 GB USB flash drive is shipped with each SkyView display. There
is nothing unique about this USB flash drive, including the data included on it.
Dynon Avionics recommends that you have a variety of USB flash drives
available for various purposes, to dedicate to a specific task. For example,
maintain a separate USB flash drive for EXPORT SETTINGS files; another for
