Appendix I: Switches, Controls, Etc. External to SkyView Units
SkyView HDX System Installation Manual - Revision E 31-1
31 Appendix I: Switches, Controls, Etc. External to
SkyView Units
Some SkyView units provide inputs or outputs for switches, other controls, indicators, etc.
that are installed external to the SkyView unit. Some of these are required (such as Servo
Disconnect / CWS), while others provide optional, additional functionality. The table below
below provides a comprehensive listing of all external switches, etc. for reference in
planning a SkyView panel, stick grip, hat switches, etc.
Detailed installation instructions for the switch or indicator are included in the
section of this manual that the button, switch, or indicator is connected to.
Table 82: Switches, etc. External to SkyView Units
SkyView Unit
Function
Pin
Number
Wire Color
Notes
Servo(s):
SV32(x)
SV42(x)
SV52(x)
Servo
Disconnect /
Control Wheel
Steering (CWS)
button
3
Yellow
Push Button Normally Open
(PBNO).
SV-AP-PANEL
Pilot Trim Up
Button
3
N/A
Push Button Normally Open
(PBNO).
Pilot Trim Down
Button
4
Copilot Trim Up
Button
5
Copilot Trim
Down Button
6
Pilot Trim Right
Button
10
Pilot Trim Left
Button
11
Copilot Trim
Right Button
12
Copilot Trim Left
Button
13
SV-COM-PANEL
Flip/Flop
7
N/A
Push Button Normally Open
(PBNO).
SV-COM-X83
Push To Talk
(PTT)
15
N/A
Push Button Normally Open
(PBNO); do not connect to a
button if using SV-INTERCOM-
2S or other audio panel.
SV-EMS-220
EMS Warning
Indicator
29
Yellow/Gre
en
Indicator.
SV-XPNDR-261
Standby
17
N/A
Single Pole Single Throw (SPST)
Switch.
Ident Pushbutton
20
N/A
Push Button Normally Open
(PBNO).
