SV-KNOB-PANEL Panel Installation
SkyView HDX System Installation Manual - Revision E 5-1
5 SV-KNOB-PANEL Panel Installation
This section contains pre-installation considerations and installation instructions and
details to install the SV-KNOB-PANEL/H (Horizontal orientation) and SV-KNOB-
PANEL/V (Vertical orientation). Physically, electronically, and operationally, the two (2)
versions are identical, and hereafter referred to SV-KNOB-PANEL.
SV-KNOB-PANEL is an optional control panel for a SkyView system that provides
dedicated function knobs for:
• ALT
• BARO
• HDG/TRK
that are otherwise operated from the multifunction knobs on a SkyView display(s). Each
SV-KNOB-PANEL knob can be pressed to sync each bug/setting, the same as using the
knobs on the SkyView display. When an SV-KNOB-PANEL is installed in a SkyView
system, the knobs on a SkyView display can still be set to ALT, BARO, and HDG/TRK if
desired. Up to two (2) SV-KNOB-PANELs can be installed in a SkyView system.
5.1 Mechanical Installation
The following diagrams as printed are NOT to scale, NOT actual size. 1:1
template drawings and CAD models are available for download at:
http://docs.dynonavionics.com (use SV-COM-PANEL drawings, which have
the same dimensions as SV-AP-PANEL).
