SkyView HDX Display Installation and Configuration
4-10 SkyView HDX System Installation Manual - Revision E
• Autopilot servos.
• SV-ADSB-472.
• SV-COM-X83.
• SV-XPNDR-261.
• Any non-Dynon Avionics device.
SkyView displays are only compatible with a Dynon Avionics SV-BAT-320
Backup Battery. Do not connect a lead-acid battery or any other battery to
the connection reserved for the SV-BAT-320, as the charging algorithm and
charging circuitry, voltages, etc., are optimized for the SV-BAT-320.
Connecting any other battery may have detrimental consequences. Damage
caused by connecting such a battery will not be repaired under warranty.
See the Non-Dynon Avionics Wire Harness Considerations, section 25.4, for
important specifications that must be adhered to for the SV-BAT-320 to
charge properly when used with a non-Dynon Avionics harness.
4.3.5 SkyView Network Connectors
The two D9 connectors on the back of a SkyView display are SkyView network
connectors. They have identical pinouts and are electrically connected inside the display
(i.e., they are completely interchangeable). Installers may use either connector or both
connectors in SkyView installations. See Page 25-10 for SkyView Network Connector
pinout information.
Note that these connectors are not “RS-232” Serial Port connectors.
4.3.6 Network Setup and Status
Once all SkyView modules are connected in a network, either in a benchtop test or
permanent installation, turn the display(s) on. You will see the display boot up and the
status LEDs on the modules light up.
A tail number on the Aircraft Information Page (SETUP MENU > SYSTEM
SETUP > AIRCRAFT INFORMATION) is required for network configuration.
If you have more than one (1) display in your SkyView system, the tail number
only needs to be set on the display that you initially perform the Network
Configuration on. At network configuration time, all other displays that are set
to the default tail number of DYNON will automatically have their settings and
tail number synchronized with the display the configuration is performed from.
After configuration, all displays’ tail numbers and settings will be synchronized,
and further setup tasks can be performed from any display.
