Display Operation
SkyView HDX System Installation Manual - Revision E 21-13
• ALTITUDE BUG ALERTER – Enter this page to configure the altitude alerter,
an audible alert when you are approaching or departing the altitude set in the
ALT bug.
o CAPTURE BAND: When the altitude of the aircraft flies within this range of
feet/meters of the altitude bug (when displayed), SkyView will announce
“approaching altitude” aurally (if audio output is configured).
o DEVIATION BAND: When the altitude of the aircraft climbs above or
descends below the altitude bug by the range of feet or meters set here,
SkyView will announce “departing altitude” aurally (if audio output is
configured).
• PFD MODE
o LAYOUT
▪ ALWAYS EFIS – The EFIS layout will always be displayed. The EFIS /
SIX-PACK button is not present in the PFD > MODE menu.
▪ SELECTABLE – the EFIS / SIX-PACK button is present in the PFD >
MODE menu, allowing either EFIS or SIX-PACK layout on PFD.
o WIDE ANGLE VIEW
▪ ALWAYS NORMAL – The NORMAL view of the horizon on the PFD will
always be displayed. The WIDE ON / OFF button is not present in the
PFD > MODE menu.
▪ ALWAYS WIDE – The WIDE view of the horizon on the PFD will always
be displayed. The WIDE ON / OFF button is not present in the PFD >
MODE menu.
▪ SELECTABLE – The WIDE ON / OFF button is present in the PFD >
MODE menu, allowing either WIDE or NORMAL views of the horizon on
the PFD.
• BARO MISMATCH WARNING – Enables / disables a warning message when
the current SkyView BARO setting and nearest valid ADS-B METARS report
barometric pressure are significantly different.
21.6.7 EMS SETUP Menu
This menu contains menus and pages related to Engine Monitoring System page and
data source (EMS module).
• ENGINE INFORMATION – Set important information regarding the engine in
your aircraft such as engine type and horsepower. The user-entered
information here is used to calculate quantities such as % power and special
operating limitations.
