Note that oil temperature is configured with a latching alarm in this example.
If oil temperature ever reaches a range configured as red, an alarm will
trigger, and a message will show up in the message box on the Main Menu.
Use this wizard to configure the style and layout of the engine and environmental sensor
gauges and calculated parameters (e.g., % power) on the 100%, 50%, 20%, and ENGINE
BOTTOM BAND Engine Pages.
Note that sensors must be defined, mapped, and configured in order to show up on an
Engine Page (reference the EMS Sensor Definitions, Mapping, and Settings Section of
this manual for instructions on how to do this).
To use this tool, enter the wizard (SETUP MENU > EMS SETUP > SCREEN LAYOUT
EDITOR), then choose the page size to edit. Once in the Screen Layout Editor, follow this
procedure:
1. Add a sensor or info widget to the screen. Press either SENSOR or INFO to show
their respective menus and scroll through available sensors or info parameters,
highlight one (1), and then press ACCEPT or move either joystick to the right to
add it to the screen.
2. Change the style of the widget. Press STYLE or turn the joystick until the widget’s
style is acceptable.
3. Change the size of the widget. Press SIZE until the widget’s size is acceptable.
4. Change the location of the widget on the screen.
a. In SkyView HDX, use the Left knob for movement of the widget to Left
(Counterclockwise) and Right (Clockwise). Use the Right knob for movement
of the widget Up (Counterclockwise), and Down (Clockwise).
5. Repeat the above steps for all sensors that you want displayed on the Engine
Page.
6. Save the page by pressing SAVE.
Press REMOVE to remove the chosen widget from the screen. Press CANCEL to return
to the EMS Setup Menu without saving any changes.
