• Reference the Loading Databases section below of this manual for instructions
on how to import the file onto a SkyView display.
Additional technical support from Jeppesen can be found online at
http://www.jeppesen.com/support/technical-support.jsp.
22.2.4 Stadium TFR Database (U.S. Only)
Dynon Avionics includes a Stadium TFR database as part of its “Quick Packages” for US
pilots. In loading any “Quick Package” since then, the Stadium TFR database will be
loaded onto a SkyView system. After the Stadium TFR database is loaded, a TFR will be
displayed on the MAP PG as if it was being received via ADS-B. The default opacity of
the Stadium TFR database (as displayed on the MAP PG) is 100% (solid Red) but can
be adjusted: MAP MENU > MAP ITEMS > TFR OPACITY.
If the Stadium TFR database is accidentally deleted from a SkyView display, contact
Dynon Avionics Technical Support to obtain a replacement Stadium TFR database.
22.2.5 Charts and Airport Diagrams
SkyView’s charting capabilities allow pilots to quickly find and display the procedures they
need during flight, all while showing the aircraft’s position and track right on the chart
itself. With the touch of a button, SkyView automatically loads the available airport
diagram while on the ground.
22.2.5.1 Geo-Referenced Charts and Airport Diagrams, Geo-referenced US
sectionals, and IFR HI and LO Charts (U.S. Only)
SkyView HDX can display geo-referenced charts and airport diagrams provided by
Seattle Avionics, including over 5,000 FlightGuide diagrams and all approach plates and
procedures. SkyView supports Seattle Avionics geo-referenced US sectionals and IFR
HI and LO charts. Subscriptions for all Seattle Avionics data listed above for SkyView
pilots are available at a special price. To order and download Seattle Avionics’ SkyView
ChartData,
contact Seattle Avionics – call 425-806-0249 or see
http://www.seattleavionics.com/ChartData/Default.aspx?TargetDevice=Dynon Avionics
