Appendix A: Maintenance and Troubleshooting
SkyView HDX System Installation Manual - Revision E 23-5
a. Load the EXPORT SETTINGS file via SETUP MENU > SYSTEM SOFTWARE
> LOAD FILES.
b. Confirm that the tail number under SYSTEM SETUP > AIRCRAFT
INFORMATION is now set to the actual aircraft tail number, not DYNON. TAIL
NUMBER should not include dashes (-) or spaces. Examples:
Correct: N12AB
Incorrect: N-12AB or N 12AB
c. Reconfigure SkyView Network under SETUP MENU > SYSTEM SETUP >
SKYVIEW NETWORK SETUP > CONFIGURE.
d. Confirm all SkyView Network components are found.
e. Confirm all settings, calibrations, and behaviors are as expected. Dynon
Avionics recommends using the Installation Manual to walk through each set
up section to confirm proper system operation.
4. If you do not have an EXPORT SETTINGS file, use the SkyView Installation
Manual to perform ALL setup and configuration steps as if the entire system is
being installed for the first time.
23.6.3 SkyView Display Scenario 3
When other display is part of a multi-display system in the aircraft, and the documentation
furnished with the repaired unit indicates that the display was shipped “like new”
1. Your repaired display will have the latest version of SkyView Software on it. All
displays in the aircraft must be on the same SkyView Software version. Therefore,
before doing anything with the repaired display, confirm that your OTHER (still
installed) SkyView displays are running the latest system Software by comparing
the version available at http://www.dynoncertified.com/software-updates.php with
the version that is listed in SETUP MENU > LOCAL DISPLAY SETUP > DISPLAY
HARDWARE INFORMATION. If the version displayed here does not match what
is available on the web site, update these displays to the most current version of
Software before proceeding further. Instructions for updating your displays can be
found in the Software Updates and File Operations section of this manual.
a. If you have to updated SkyView Software, look through all the settings in the
SETUP MENU after the update, as there may be some new options. Use the
Revision History at the beginning of the SkyView System Installation Manual to
help determine what has changed between versions.
2. Reinstall the repaired display, reconnecting all harnesses and connections as
originally installed.
3. Power up the entire SkyView System (all displays, modules, servos, etc.).
4. From the display that never left the airplane, save your settings files to a USB flash
drive by using SETUP MENU > EXPORT SETTINGS …
