24.9 SV-GPS-2020 Specifications
Table 57: SV-GPS-2020 Specifications
Specification
Parameters
Description
WAAS GPS Receiver / Antenna
Compliance
Meets 14 CFR § 91.225, 14 CFR § 91.227, and
performance requirements of TSO-c166b
Source Integrity Level (SIL)
3
System Design Assurance (SDA)
2
Update Rate
4 Hz
Receives WAAS Correction Signals
(where available)
Yes
Uses all available positioning satellites?
No (L1 only)
Time to Acquire Fix (cold start)
60 Seconds
Data Interface
TX – Grey/Violet
RS-232C @ 115,200 baud
RX – Grey/Orange
RS-232C (not currently implemented)
NMEA data sentences
GPGGA, GPGLL, GPGSA, GPGSV, GPRMC,
GPVTG, GPZDA (additional proprietary data)
Transponder Compatibility
Dynon Avionics SV-XPNDR-261
(minimum Software SW02.08)
System Compatibility
Dynon Avionics SkyView system
minimum Software: v14.0
Advanced Flight Systems AF-5000 system
minimum Software: v14.0
Maximum Altitude
60,000 Feet (18,200 Meters)
Maximum Velocity
400 Knots (740.8 KPH)
Size
2.19 in. W x 0.75 in. H x 3.44 in. D
(55.63mm W x 19.05mm H x 87.38mm D)
Weight
7 oz. (198g)
Power Requirements
8V, 0.1A (Orange Wire +)
Electrical Ground (Black Wire -)
Operating Temperature
-4°F to +158°F (-20°C to +70°C)
Storage Temperature
-40°F to +140°F (-40°C to +60°C)
