Appendix G: Sensor Debug Data
28-4 SkyView HDX System Installation Manual - Revision E
this does not clear History Data Log, as this is a log of all significant changes to the
configuration of the SkyView system.
28.1.6 Exporting Data Logs
In a dual engine configuration (dual SV-EMS-22x with at least two (2)
SkyView displays), data logs for each engine are recorded / exported only on
the display that is monitoring each engine. Example – in a system where the
left display is configured to monitor the left engine, the data log exported from
the left display contains the data log for the left engine (only). It is
recommended to use a separate USB flash drive per engine to prevent the
possibility of overwriting data logs.
Connect a USB flash drive with at least 100 MB of available storage capacity to your
SkyView display. Then, navigate to SETUP MENU > SYSTEM SOFTWARE > EXPORT
USER DATA LOGS to export the three (3) data logs to the USB flash drive.
If your SkyView system has not yet flown, or has not flown since the data logs were last
cleared, there may not be a Recent Flight Data Log available.
The data logs that are exported are in CSV (comma separated values) format and can be
opened by common spreadsheet programs such as Microsoft Excel.
28.1.6.1 Web-based Engine Analysis
Savvy Analysis – http://www.savvyanalysis.com is a free web-based tool that supports
the upload and analysis of the engine information that is contained within SkyView’s User
Data Logs. Instructions for creating an account and uploading data logs are on the Savvy
Analysis website.
Other than technical cooperation to ensure that SkyView data logs can be correctly
parsed as formats are periodically updated, Dynon Avionics has no relationship with
Savvy Analysis.
