SV-ARINC-429 Module Installation and Configuration
SkyView HDX System Installation Manual - Revision E 13-3
The SV-ARINC-429 does not provide mounting hardware. The mounting tabs on each
side of the module have holes sized for #10 fasteners, but it is up to the installer to decide
how the SV-ARINC-429 will be secured to the aircraft.
Follow recommended torque practices when tightening the mounting hardware. Do not
rivet the SV-ARINC-429 to the aircraft as this will hinder future removal if necessary.
13.2 Electrical Installation
Connect the SV-ARINC-429 module to the SkyView network using the hardware
mentioned in Section 2.11, or using equivalent hardware.
If you have to install a connector on the end of a network cable, insert all pins into the D9
connector. Refer to Section 25 Appendix C: Wiring and Electrical Connections for details
on connector pinouts and wire colors.
13.2.1 ARINC-429 SkyView Connection
13.2.1.1 Harness Construction
Because the SV-ARINC-429 can be connected to a variety of devices, the harness
requirements will vary from airplane to airplane. Therefore, Dynon Avionics does not
supply pre-manufactured harnesses for the SV-ARINC-429 module. Instead, your SV-
ARINC-429 shipped with enough connectors and pins to generate a wide variety of
harness configurations. Refer to the sections below for detailed wiring information.
If you do not own a DSUB machined-pin crimping tool, they can be obtained from many
electronics or avionics dealers. You may also find it helpful to own a pin
insertion/extraction tool as well.
Additional harness construction and wiring information can be found in Section 25
Appendix C: Wiring and Electrical Connections.
The SV-ARINC-429 has a single D25F connector which is used for all data connections
to your compatible ARINC-429 device. The pin out depicted in Figure 88 below depicts
the view from the rear of your D25M connector – the view you will have of your harness
connector as you are inserting pins into the harness. Note that the pin numbers are
labelled on the face of both the female and male connector.
