– of all of the recorded fields. Because different SkyView systems have different EMS pin
mappings, the order and content of the columns can be dynamic from system to system.
The User Data Log records at the selected Record Rate (see below) any time the SkyView
system is powered on.
A sample of what a few columns and rows of data would look like when viewed in a
spreadsheet program is shown below. An actual user data log would have over 100
columns of data, and many thousands of rows:
Table 81: User Data Log Excerpt Example
System
Time
Pitch
(deg)
Roll
(deg)
Magnetic
Heading
(deg)
Indicated
Airspeed
(knots)
Pressure Altitude
(ft.)
1:50:38
0.2
-1.7
134.4
0
4364
1:50:38
0.2
-1.8
134.4
0
4364
1:50:38
0.2
-1.8
134.3
0
4364
1:50:38
0.2
-1.8
134.4
0
4364
1:50:39
0.2
-1.8
134.4
0
4364
1:50:39
0.2
-1.7
134.4
0
4364
28.1.2 Recent Flight Data Log
Filename format:
2014-08-07-N123X-SKYVIEWDISPLAYSERIALNUMBER-SOFTWAREVERSION-
OPTIONAL33CHARACTERS-BLACK_BOX_LOG_DATA.csv
Example:
2014-08-07-N123X-SN1492-11.0-CROSS_COUNTRY_LEG1-
BLACK_BOX_LOG_DATA.csv
(CROSS_COUNTRY_LEG1 is user-selectable text, up to 33 characters, at time of
export.)
The Recent Flight Data Log records the most recent 15 minutes of flight at a data
recording rate of 16 times per second, in the same manner as described above. Its
recording rate cannot be changed.
The Recent Flight Data Log records data whenever SkyView believes that it is in flight,
which it determines by observing IAS and/or GPS ground speed.
28.1.3 Alert Data Log
Filename format:
DATE-TAILNUMBER-SKYVIEWDISPLAYSERIALNUMBER-SOFTWAREVERSION-
OPTIONAL33CHARACTERS-ALERT_DATA.csv
Example:
2014-08-07-N123X-SN1492-11.0-CROSS_COUNTRY_LEG1-ALERT_DATA.csv
