EFIS-D10A Standby Display Installation and Configuration
SkyView HDX System Installation Manual - Revision E 20-3
20.7 Mechanical Installation
The following diagram shows the outside dimensions of the front bezel of the EFIS- D10A.
Note that the instrument is about seven inches deep and the Dynon-made harness
extends three inches more. Use the dimensions (in inches) found on the diagram to plan
for the space required by the instrument. Take the following considerations into account
when selecting a mounting location for the EFIS-D10A.
Avoid placing the instrument near heater vents or any source of extremely hot or cold air.
The air surrounding the EFIS-D10A during operation may be no warmer than 50 C to
ensure accurate operation. Plan a panel location that allows convenient viewing of the
instrument with no obstruction. When flying straight and level, the panel angle from
vertical may not be greater than +/- 30 degrees. The unit must also be parallel to the roll
axis of the aircraft (although not necessarily located along it), and have no significant roll
angle in the panel. The firmware supports an adjustment for panel tilt, but not for mounting
errors in yaw or roll. Correct attitude performance depends on mounting the EFIS-D10A
square with the direction of flight.
