Appendix B: Specifications
SkyView HDX System Installation Manual - Revision E 24-1
24 Appendix B: Specifications
24.1 Minor Unit Physical Specifications
Table 50: SkyView Minor Equipment Weights
SkyView / Dynon Avionics Equipment Description
Approx. Weight
Ammeter Shunt
0.32 lb. (0.14 kg)
AOA/Pitot Probe, unheated
0.36 lb. (0.16 kg)
Antenna – 978 MHz (for ADS-B)
0.05 lb. (0.02 kg)
Antenna – 1090 MHz (for Transponder)
0.05 lb. (0.02 kg)
Carburetor Air Temperature Sensor
0.13 lb. (0.06 kg)
Capacitance to Voltage Converter (single)
0.08 lb. (0.04 kg)*
CHT Sensor (single)
0.08 lb. (0.04 kg)*
EGT Sensor (single)
0.09 lb. (0.04 kg)*
EMS 37-pin Main Sensor Harness
0.81 lb. (0.37 kg)
EMS EGT/CHT 4-cylinder 25-pin Thermocouple Wire Harness
0.71 lb. (0.32 kg)
EMS EGT/CHT 6-cylinder 25-pin Thermocouple Wire Harness
0.69 lb. (0.31 kg)
Fluid Pressure Sensor – Kavlico, with pigtail
0.11 lb. (0.05 kg)*
Fuel Flow Transducer (single)
0.24 lb. (0.11 kg)*
Manifold Pressure Sensor
0.20 lb. (0.09 kg)
OAT Sensor
0.09 lb. (0.04 kg)
SV-ETHERNET-3CC
0.07 lb. (0.03 kg)
SV-HARNESS-D37
0.47 lb. (0.21 kg)
SV-NET-1.5CC
0.16 lb. (.071 kg)
SV-NET-3CC
0.21 lb. (0.10 kg)
SV-NET-6CC
0.33 lb. (0.15 kg)
SV-NET-10CP
0.49 lb. (0.22 kg)
SV-NET-15CP
0.68 lb. (0.31 kg)
SV-NET-20CP
0.87 lb. (0.40 kg)
SV-NET-25CP
1.07 lb. (0.49 kg)
SV-NET-30CP
1.26 lb. (0.57 kg)
SV-NET-HUB
0.19 lb. (0.09 kg)
SV-NET-SERVO
0.70 lb. (0.32 kg)
SV-NET-SPL
0.20 lb. (0.09 kg)
Single sensor / accessory. Multiply by the number for total weight of sensors /
accessories.
24.2 SkyView Compatible Engine Sensors (sold by Dynon Avionics)
Table 51: SkyView Compatible Engine Sensors
Description
Range/Type
Fittings
Dynon Avionics
P/N
Amps Shunt or
Ammeter Shunt
0-60 A
(can be configured to
display -60 A to +60 A)
2 each 1/4” Ring
Terminals
503386-000
