Appendix B: Specifications
24-2 SkyView HDX System Installation Manual - Revision E
Description
Range/Type
Fittings
Dynon Avionics
P/N
Carburetor Air
Temperature
-50° F to 150° F
1/4-28 UNF
503416-000
CHT (for Lycoming/
Continental/Superior)
J-Type Thermocouple
Bayonet 3/8-24 UNF
503382-000
EGT (for Lycoming/
Continental/Superior)
K-Type Thermocouple
1/8” hole, Hose Clamp,
1” – 2”
503384-000
EGT (for Rotax)
K-Type Thermocouple
1/8” hole, Hose Clamp
1/4” – 1 1/4”
503384-000
Fuel Flow Sensor
0.6 GPH -70+ GPH
1/4” Female NPT
503380-000
Fuel Pressure – Kavlico
0-50 PSI
1/8-27 NPT
503389-000
Manifold Pressure
(MAP)
0-60 In Hg
Nipple fitting: 1/4” ID
tubing recommended
503387-000
OAT Sensor
-40° F to 150° F
3/8” hole in fuselage,
9/16” nut
503291-000
Oil Pressure – Kavlico
0-150 PSI
1/8-27 NPT
503388-000
Oil Temperature
(for Lycoming/
Continental/Superior)
-10° F to 300° F
5/8-18 UNF
503385-000
Oil Temperature (for
older Continental 0-
200s)
-10° F to 300° F
1/8-27 NPT
100409-000
