Dynon SkyView HDX - EMS Sensor Settings

SV-EMS-220 Engine Monitoring System Installation and Configuration
SkyView HDX System Installation Manual - Revision E 10-25
Loading a premade sensor mapping file onto SkyView can save installation
time. These files define sensors with the four (4) parameters mentioned.
The table below shows an example oil pressure sensor map on pin 6 of the SV-EMS-220
D37 connector.
Table 20: Example Sensor Map
PIN #
FUNCTION
SENSOR
NAME
C37 P6
PRESSURE
150 PSI FLUID PRESSURE (503388-000)
OIL
10.7.2.2 Manual Sensor Mapping
Appendix D: SV-EMS-220 Sensor Input Mapping Worksheet is a useful tool
during sensor mapping. This section is intended for use only if the premade
sensor mapping file does not contain the sensor definitions needed for your
installation.
Go to the Sensor Input Mapping Wizard (SETUP MENU > EMS SETUP > SENSOR
INPUT MAPPING…) and use the following procedure to manually map a sensor or
transducer:
1. Scroll through the different parameters using a combination of joystick turns and
movements in the up, down, left, and right motions. The selected parameter is
highlighted, and its text is enlarged.
2. Press SELECT to open the parameter for editing.
3. Edit the parameter using a series of joystick turns and movements.
4. Save the parameter edit by pressing ACCEPT or by moving either joystick to the
right or the left. Press CANCEL to back out of the parameter edit mode without
saving.
10.7.3 EMS Sensor Settings
Mapped sensors that are displayed on the Engine Page should have their alert and
graphical properties appropriately configured. This section explains the settings that are
required for EMS sensors, contains instructions for manually configuring sensor settings,
and uses several sensor settings examples to further explain sensor settings.
SkyView EMS sensor settings are defined by the following parameters in the Sensor
Setup Menu:
• ALARM.
• MAXIMUM GRAPHICAL DISPLAY.
• MINIMUM GRAPHICAL DISPLAY.
• SHOW SENSOR UNITS.
• RANGE (1-5).
