Display Operation
SkyView HDX System Installation Manual - Revision E 21-1
21 Display Operation
After reading this section, you should be familiar with basic SkyView display operation
including how to use joysticks, knobs, and buttons, how to turn displays on and off, how
to access and navigate menus, how to configure the SkyView network, and how to
perform Software updates and other file operations.
The SkyView SV-HDX800 and SV-HDX1100 displays are identical in
functionality and presentation. The only difference is in the size of the screen.
21.1 Screen Synchronization
SkyView is designed to operate as an integrated system. SkyView configurations with
more than one (1) display automatically share and synchronize settings on all displays.
In-flight settings such as baro and bugs are synchronized in real time as they are adjusted.
Setup menu items are synchronized when the user exits the setup menu and also at boot
up. Aviation and obstacle databases are synchronized when they are loaded on any
screen if Ethernet is connected.
It is not possible to have displays on the same network that do not share configurations,
settings, and real-time items. Even if a unit is off when settings are adjusted, they will be
synchronized when they boot up.
For displays to properly synchronize settings their tail numbers must be the
same and SkyView Network must be configured correctly. See the Network
Setup and Status Section of this manual for information about these required
setup steps.
Only one (1) setup menu in the network may be open at once. If you try to open a setup
menu on a display while it is open on another display, you will see OTHER SCREEN IN
SETUP on the screen and thus cannot open the setup menu. There is no "master" in the
system; changes made on any screen in the system will be automatically reflected on all
other screens.
Some things are purposefully not synchronized on displays: Software, sensor
configuration files (.sfg), and local display settings. You must ensure that each display is
running the appropriate Software, up-to-date databases, and sensor configuration file. All
of these files are available for download at http://downloads.dynonavionics.com. Also
ensure that each display’s local settings are appropriately configured.
