Dynon SkyView HDX - SV-COM-T8 Environmental Qualification

Appendix B: Specifications
24-8 SkyView HDX System Installation Manual - Revision E
24.8 SV-COM-T8 Environmental Qualification Form
Table 56: SV-COM-T8 Environmental Qualification Form
Conditions
DO-160F
Section
Description of Conducted Tests
Nomenclature:
TY91L VHF radio
Part Number: 00882-00-01
ETSO: 2C169a
Manufacturer:
Trig Avionics Limited
Address:
Heriot Watt Research Park, Riccarton, Edinburgh, Scotland,EH14
4AP
Temperature and Altitude
4.0
Equipment tested to Categories A2, C1
Low temperature ground
survival
4.5.1
-55°C
Low temperature short-time
operating
4.5.1
-40°C
Low temperature operating
4.5.2
-20°C
High temperature operating
4.5.4
+70°C
High temperature short-time
operating
4.5.3
+70°C
High temperature ground
survival
4.5.3
+85°C
Loss of Cooling
4.5.5
Cooling air not required
(+70°C operating without cooling air)
Altitude
4.6.1
55,000 feet
Decompression
4.6.2
8,000 to 55,000 feet in 15 seconds
Overpressure
4.6.3
-15,000 feet
Temperature Variation
5.0
Equipment tested to Category B
Humidity
6.0
Equipment tested to Category A
Operational Shocks
7.2
Equipment tested to Category B
Crash Safety
7.3
Equipment tested to Category B type 5
Vibration
8.0
Aircraft zone 2; type 3, 4, 5 to category S Level M, type 1
(Helicopters) to category U Level G
Explosion
9.0
Equipment identified as Category X – no test required
Waterproofness
10.0
Equipment identified as Category X – no test required
Fluids Susceptibility
11.0
Equipment identified as Category X – no test required
Sand and Dust
12.0
Equipment identified as Category X – no test required
Fungus
13.0
Equipment identified as Category X – no test required
Salt Spray
14.0
Equipment identified as Category X – no test required
Magnetic Effect
15.0
Equipment tested to Category Z, safe distance 1 meter
Power Input
16.0
Equipment tested to Category BX
Voltage Spike
17.0
Equipment tested to Category B
Audio frequency conducted
susceptibility
18.0
Equipment tested to Category B
Induced signal susceptibility
19.0
Equipment tested to Category AC
Radio frequency
susceptibility
20.0
Equipment tested to Category TT
Radio frequency emission
21.0
Equipment tested to Category B
Lightning induced transient
susceptibility
22.0
Equipment tested to Category B2H2L2
Lightning direct effects
23.0
Equipment identified as Category X – no test required
Icing
24.0
Equipment identified as Category X – no test required
Electrostatic Discharge
25.0
Equipment identified as Category X – no test required
Fire, Flammability
26.0
Equipment identified as Category C
