Dynon SkyView HDX - Page 23

System Overview
SkyView HDX System Installation Manual - Revision E 2-3
Table 1: Typical Instrument Panel Mounted Equipment
Item
Description
1
HDX1100 Primary Display
2
SV-BAT-320 Backup Battery
3
EFIS-D10A Standby Display
4
SV-COM-X83 COM Radio Control Panel
5
SV-AP-PANEL Autopilot Control Panel
6
SV-KNOB-Panel Knob Control Panel
7
SV-BUTTON-APDISC Autopilot Disconnect Button
8
SV-ARINC-429 ARINC 429 Interface Module
9
SV-ADAHRS-200 ADAHRS
10
SV-EMS-220 Engine Monitoring System
11
SV-ADSB-472 ADS-B Receiver
12
HDX1100 Avionics Tray
13
SV-COM-X83 COM Radio Transceiver
14
SV-XPNDR-261 Transponder Mode-S
17
HDX800 Secondary Display
18
HDX800 Secondary Display Avionics Tray
19
SV-BAT-320 Backup Battery
