Appendix G: Sensor Debug Data

29-8 SkyView HDX System Installation Manual - Revision E

0diff: VALUE should be near 0.4. This only affects thermocouples.

ColdJ: Cold junction, which is the temp of the EMS box. VALUE should be the temp of

the EMS box in degrees F. This only affects thermocouples.
