SkyView HDX Display Installation and Configuration
4-18 SkyView HDX System Installation Manual - Revision E
ICARUS
Garmin GTX328 (Garmin serial port must be set to Icarus input),
Icarus,
Trimble
Baud rate
9600
Format
ALT, space, five (5) altitude bytes, carriage return
Example message
ALT 05200[CR]
4.3.9.8 Non-Dynon Avionics Transponder
SkyView can display the status of the Garmin GTX 327 and Garmin GTX 330 / 330ES
transponders. To use this functionality with SkyView:
• Wire a serial receive line to the respective transmit line on the transponder. If
you have more than one (1) SkyView display, make the same connection to all
SkyView displays.
• Ensure there is a shared ground between the SkyView display and the
transponder. If you have more than one (1) SkyView display, make the same
connection to all SkyView displays.
• Configure the serial port on each display appropriately under SETUP MENU >
SYSTEM SETUP > SERIAL PORT SETUP.
• Configure the serial port on the transponder appropriately. For a Garmin GTX
327, 330 / ES, the RS-232 output of the appropriate serial port on the
transponder should be set to REMOTE+TIS.
4.3.9.9 Garmin SL30 COM / NAV Radio
In addition to the NAV radio functions of the SL30, SkyView can display COM radio
information from the SL30 on the top bar of the SkyView display(s) and send COM
frequencies to the SL30 (TUNE COM).
• Connect SL30 serial RX pin 4 (RxD1) to a SkyView serial TX. If you have more
than one (1) SkyView display, make the same connection to all SkyView
displays.
• Connect SL30 serial TX pin 5 (TxD1) to a SkyView serial RX. If you have more
than one (1) SkyView display, make the same connection to all SkyView
displays.
• Ensure there is a shared ground between the SkyView display and the SL30.
If you have more than one (1) SkyView display, make the same connection to
all SkyView displays.
• Configure the serial port on the SL30 appropriately. On the SL30, the Indicator
Head Type should be set to NONE.
