4. Troubleshooting
45530
45530
Error: Processor 2
No. 05550
Drive Motor has stopped.
Error message release
YES
Condition
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00000 The drive motor has stopped due to the protected operation.
Failed part Manual No.
Drive motor
☞63290
Processor relay PCB ☞66220
Processor control PCB ☞66200
Drive motor driver PCB (QSS-3704, QSS-3705, LP7700 and LP7900 only)
☞66870
Symptoms due to the wiring connection failure Symptoms of fuse blowout
− ☞4203 −
