4. Troubleshooting
46100
15/33
46100
Error message: Printer 2
No. 06151
Paper Loading Sensor error.
Error message release
YES
NOTE
• ☞No. 06151 Paper Loading Sensor error. is shown in the versions earlier than 5.0 for the QSS-Printer, versions earlier than 3.0 for
the FRONTIER-Printer.
Condition
NOTE
• The suffix number differs depending on the operation which is currently processed.
Check Point
NOTE
• In the service mode, LED light intensity value is displayed in the Paper Sensor Adjust.
• After cleaning the sensor, carry out Paper Sensor LED Light Intensity Adjustment again and check that the sensor LED light
intensity changes.
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Condition
- Each print sensor was not adjusted properly when Paper Sensor LED Light Intensity Adjustment was
performed in Functions of Paper Sensor Adjustment.
Suffix number Condition
00001 When the light source level of the emission sensor is set to 0, the detection sensor does not turn DARK.
00002 When the light source level of the emission sensor is set to 255, the detection sensor does not turn LIGHT.
00003 When the light source level of the emission sensor is set to 1/9 of setting value, the detection sensor does not turn
DARK.
00004 When the light source level of the emission sensor is set to the setting value, the detection sensor does not turn
LIGHT.
1 Clean the paper loading sensor using a blower brush.
2 Confirm the sensor status on the Paper Sensor Adjustment display. ☞36000
Failure Manual No.
Paper loading sensor ☞63060
Printer I/O PCB 2
☞66030
Printer I/O PCB 1
☞66020
Printer control PCB ☞66000
