Paper advance operation
6. The paper is transferred to the exposure advance unit, and then paper supply pressure is released.
• Paper supply pressure change motor: ON (released)/OFF
When the paper supply pressure change sensor does not turn dark:
• ☞ No. 06134-00002
Paper Supply Pressure Change Motor operation error.
Note: The thick solid line indicates the paper.
Cut end sensor
Cut home sensor
Cut motor
G069828
Paper supply pressure change sensor
Paper supply pressure change motor
Note: The thick solid line indicates the paper.
G069829
