5. Operation sequence
55510
4/6
55510
Paper advance operation
Lane Select Motor (Left) operation error.
7. Paper is advanced to arm unit 2 (left).
8. Arm unit 2 (left) pressures the paper.
• Paper advance pressure change motor (left): ON (pressured)/OFF
If the paper advance pressure change sensor (left) does not turn DARK
• ☞ No. 06142-00001
Paper Advance Pressure Change Motor (Left) operation error.
9. Arm unit 2 (left) moves to the paper advance standby position.
• Paper advance arm motor (left): ON/OFF
If the arm sensor (left) does not turn LIGHT
• ☞ No. 06138-00002
Paper Advance Arm Motor (Left) operation error.
G069947
G069949
