5. Operation sequence
56600
3/3
56600
Colorimeter unit operation
7. After the paper sensor 1 detects that the calibration plate passed, moves for a specified length, the
calibration plate stops at the standby position.
• Paper sensor 1: DARK to LIGHT
• Calibration plate advance motor: ON (reverse)/OFF
If paper sensor 1 does not turn LIGHT
• ☞No. 06554-00006
Calibration Plate advance error.
8. Apply pressure to the measuring position without the calibration plate.
• Pressure solenoid: OFF
9. Judge and register the result of the calibration plate, calibrate the colorimeter.
For details of the judgment, refer to ☞Judgment operation of setup print.
