5. Operation sequence
57010
8/8
57010
Replenishment operation sequence [F]
• Replenisher Cartridge Position Sensor (Lower): LIGHT → DARK
If Replenisher Cartridge Position Sensor (Upper) does not turn LIGHT
• ☞No. 05900[F]−0010Replenisher cartridge open motor operation error.
If Replenisher Cartridge Position Sensor (Lower) does not turn DARK
• ☞No. 05900[F]−0011Replenisher cartridge open motor operation error.
25. The replenisher cartridge is moved from the lower position to the upper position.
• Replenisher Cartridge Open Motor: ON → OFF
• Replenisher Cartridge Position Sensor (Lower): DARK → LIGHT
• Replenisher Cartridge Position Sensor (Upper): LIGHT → DARK
If Replenisher Cartridge Position Sensor (Lower) does not turn LIGHT
• ☞No. 05900[F]−0013Replenisher cartridge open motor operation error.
If Replenisher Cartridge Position Sensor (Upper) does not turn DARK
• ☞No. 05900[F]−0014Replenisher cartridge open motor operation error.
26. End
