Position of PCBs (processor section)
1/2
6. Electrical parts
63201-5
63201-5
Position of PCBs (processor section)
Processor section (PCB positions) (QSS-3704/3705/LP7700/LP7900)
[F][N][SM]
This item varies depending on the specification and model. See the references below.
!
!!
! Layout diagram
Processor section
Model Reference
QSS-3704 [SM] ☞Processor section (PCB positions) (QSS-3704) [SM]
QSS-3701/3702/3703/LP7500/LP7600 [F][N][SM][J]
☞63200
No. Name Symbol Manual No. Remarks
1 Processor control PCB ☞66200
2 Processor I/O PCB 1
☞66210
3 Processor I/O PCB 2
☞66211
4 Processor relay PCB ☞66220
2
6
5
1
4
QSS-3704/3705 [N]/QSS-3704 [SM]
3
8
G085373
QSS-3704/3705/LP7700/LP7900 [F]
1
4
2
7
Back: 5
3
8
Front: 6
G085375
