2/4
6. Electrical parts
63280
63280
Positions of electrical parts (Processor section)
*1. For details about processor section fan operation specification, see ☞63321.
*2. After replacing each electrical part, see Processor section (List of adjustment after electrical parts replacement)
☞63312.
5 PS3 processing solution float switch FS5
PS3 processable level
6 PS4 processing solution float switch FS6
PS4 processable level
7CD thermosensor TH1
8 BF thermosensor TH2
9 STB thermosensor TH3
10 P1 Heater H1
11 P2 Heater H2
12 PS Heater H3
13 Minute Meter CO Option
14 Power supply cooling fan 1 FAN14 Exhaust
*1
15 CD circulation pump P1
16 BF circulation pump P3
17 STB1 circulation pump P5
18 STB2 circulation pump P6
19 STB3 circulation pump P7
20 STB4 circulation pump P8
21 Tank cooling fan 1 FAN4 Intake
*1
22 CD digital flowmeter FLS1 Option
23 P1R Replenisher Pump RP1
*2
24 P2RA Replenisher Pump RP2
25 P2RB Replenisher Pump RP3
26 PSR Replenisher Pump RP4
27 Earth leakage circuit breaker 1 NFB2 See
☞4203.
28 Earth leakage circuit breaker 2 NFB3
29 Earth leakage circuit breaker 3 NFB4
30 Terminal strip 1 TA1
31 Terminal strip 2 TA2
32 Interlock switch (Processor top cover) LS4
33 Transformer TR1
No. Name Symbol Remarks
