I-2 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.1 FACTORY DEFAULT SETTINGS APPENDIX I: FACTORY DEFAULT CONFIGURATION
Product Setup > Communication Settings > Network (Ethernet)
Network (Ethernet)1 > Network (Ethernet)
Setting Description Name Default Value Step Range
User
Value
1st octet of IP address IP Address Oct1 0 N/A [0 : 255]
2nd octet of IP address IP Address Oct2 0 N/A [0 : 255]
3rd octet of IP address IP Address Oct3 0 N/A [0 : 255]
4th octet of IP address IP Address Oct4 0 N/A [0 : 255]
1st octet of Netmask Netmask Oct1 0 N/A [0 : 255]
2nd octet of Netmask Netmask Oct2 0 N/A [0 : 255]
3rd octet of Netmask Netmask Oct3 0 N/A [0 : 255]
4th octet of Netmask Netmask Oct4 0 N/A [0 : 255]
**For firmware versions 7.00 or higher; on the Network settings are also located the settings for Redundancy.
Setting Description Name Default Value Step Range
User
Value
Function permission
REDUNDANCY
MODE
INDEPENDENT N/A [INDEPENDENT; LLA;
PRP; HSR; RSTP;
DAISY_CHAIN]
Stablish priority for Port A
LLA Priority DISABLED N/A [ENABLED; DISABLED]
Switch over time from port B to port A
LLA Timeout 5000 N/A [0 : 600000]
Switch (bridge) priority value
RSTP BRIDGE
PRIORITY
32768 N/A [0 : 61440]
determine which ports are used for
forwarding
RSTP PORT A
PRIORITY
128 N/A [0 : 240]
assigned port cost value used for the switch
RSTP PORT A
PATHCOST
200000 N/A [0 : 2000000]
Determine which ports are used for
forwarding
RSTP PORT B
PRIORITY
128 N/A [0 : 240]
Assigned port cost value used for the switch
RSTP PORT B
PATHCOST
200000 N/A [0 : 2000000]
Product Setup > Communication Settings > Modbus Protocol
Setting Description Name Default Value Step Range
User
Value
Slave address for COM1
Modbus Address
CO
M1
254 N/A [1 : 255]
Slave address for COM2
Modbus Address
CO
M2
254 N/A [1 : 255]
Modbus port number for Modbus TCP/IP Modbus Port Number 502 N/A [0 : 65535]
Product Setup > Communication Settings > DNP3 Slave
DNP3 Slave 1 > DNP3 Slave 2 > DNP3 Slave 3
Setting Description Name Default Value Step Range
User
Value
Communications port assigned to the DNP
pr
otocol
Physical Port NONE N/A [COM1:COM2:NETWORK]
DNP slave address Address 255 N/A [0 : 65534]
1st Octect of IP address of DNP master 1 IP Addr Client1 Oct1 0 N/A [0 : 255]
2nd Octect of IP address of DNP master 1 IP Addr Client1 Oct2 0 N/A [0 : 255]
3nd Octect of IP address of DNP master 1 IP Addr Client1 Oct3 0 N/A [0 : 255]
