APPENDIX I: FACTORY DEFAULT CONFIGURATION I.1 FACTORY DEFAULT SETTINGS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-3
4th Octect of IP address of DNP master 1 IP Addr Client1 Oct4 0 N/A [0 : 255]
1st Octect of IP address of DNP master 2 IP Addr Client2 Oct1 0 N/A [0 : 255]
2nd Octect of IP address of DNP master 2 IP Addr Client2 Oct2 0 N/A [0 : 255]
3nd Octect of IP address of DNP master 2 IP Addr Client2 Oct3 0 N/A [0 : 255]
4th Octect of IP address of DNP master 2 IP Addr Client2 Oct4 0 N/A [0 : 255]
1st Octect of IP address of DNP master 3 IP Addr Client3 Oct1 0 N/A [0 : 255]
2nd Octect of IP address of DNP master 3 IP Addr Client3 Oct2 0 N/A [0 : 255]
3nd Octect of IP address of DNP master 3 IP Addr Client3 Oct3 0 N/A [0 : 255]
4th Octect of IP address of DNP master 3 IP Addr Client3 Oct4 0 N/A [0 : 255]
1st Octect of IP address of DNP master 4 IP Addr Client4 Oct1 0 N/A [0 : 255]
2nd Octect of IP address of DNP master 4 IP Addr Client4 Oct2 0 N/A [0 : 255]
3nd Octect of IP address of DNP master 4 IP Addr Client4 Oct3 0 N/A [0 : 255]
4th Octect of IP address of DNP master 4 IP Addr Client4 Oct4 0 N/A [0 : 255]
1st Octect of IP address of DNP master 4 IP Addr Client5 Oct1 0 N/A [0 : 255]
2nd Octect of IP address of DNP master 4 IP Addr Client5 Oct2 0 N/A [0 : 255]
3nd Octect of IP address of DNP master 4 IP Addr Client5 Oct3 0 N/A [0 : 255]
4th Octect of IP address of DNP master 4 IP Addr Client5 Oct4 0 N/A [0 : 255]
TCP/UDP port number for DNP over
Ether
net
TCP/UDP Port 20000 N/A [0 : 65535]
Unsolicited responses permission Unsol Resp Function DISABLED N/A [DISABLED – ENABLED]
Time out to confirm an unsolicited response Unsol Resp TimeOut 5 1 s [0 : 60]
Number of retransmissions of an unsol resp
w/o conf
irmation
Unsol Resp Max Ret 10 N/A [0 : 255]
Address to which all unsolicited responses
ar
e sent
Unsol Resp Dest Adr 200 N/A [0 : 65519]
Scale for currents Current Scale Factor 1 N/A
[0.00001-0.0001-0.001-
0.01-0.1-1-1
0-100-1000]
Scale for voltages Voltage Scale Factor 1 N/A
[0.00001-0.0001-0.001-
0.01-0.1-1-1
0-100-1000]
Product Setup > Communication Settings > DNP3 Slave (CONT.)
DNP3 Slave 1 > DNP3 Slave 2 > DNP3 Slave 3
Setting Description Name Default Value Step Range
User
Value
Scale for power Power Scale Factor 1 N/A
[0.00001-0.0001-0.001-
0.01-0.1-1-1
0-100-1000]
Scale for energy Energy Scale Factor 1 N/A
[0.00001-0.0001-0.001-
0.01-0.1-1-1
0-100-1000]
Other Scale factor Other Scale Factor 1 N/A
[0.00001-0.0001-0.001-
0.01-0.1-1-1
0-100-1000]
Default deadband for Current Analog Input
point
s to trigger unsolicited responses
Current Deadband 30000 N/A [0 : 65535]
Default deadband for Voltage Analog Input
point
s to trigger unsolicited responses
Voltage Deadband 30000 N/A [0 : 65535]
Default deadband for Power Analog Input
point
s to trigger unsolicited responses
Power Deadband 30000 N/A [0 : 65535]
Default deadband for Energy Analog Input
point
s to trigger unsolicited responses
Energy Deadband 30000 N/A [0 : 65535]
Default deadband for Other Analog Input
point
s to trigger unsolicited responses
Other Deadband 30000 N/A [0 : 65535]
Size (in bytes) for message fragmentation Msg Fragment Size 240
1
byt
e
[30 : 2048]
