APPENDIX I: FACTORY DEFAULT CONFIGURATION I.1 FACTORY DEFAULT SETTINGS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-5
DNP Analog Input Points point list
Analog Input Point 24 End of list N/A
DNP Analog Input Points point list
Analog Input Point 25 End of list N/A
DNP Analog Input Points point list
Analog Input Point 26 End of list N/A
DNP Analog Input Points point list
Analog Input Point 27 End of list N/A
DNP Analog Input Points point list
Analog Input Point 28 End of list N/A
DNP Analog Input Points point list
Analog Input Point 29 End of list N/A
DNP Analog Input Points point list
Analog Input Point 30 End of list N/A
DNP Analog Input Points point list
Analog Input Point 31 End of list N/A
DNP Notes
Note 1: Scale Factor
Note that a scale factor of 0.1 is equivalent to a multiplier of 10 (i.e. the value is 10 times
Note 2: Binary Input Block Selection:
[NOT USED, CTL EVENTS 1-16, CTL EVENTS 17-32, CTL EVENTS 33-48,CTL EVENTS 49-64,
CT
L EVENTS 65-80, CTL EVENTS 81-96, CTL EVENTS 97-112, CTL EVENTS 113-128,
Product Setup > Communication Settings > IEC 870-5-104
Setting Description Name Default Value Step Range
User
Value
Enable or disable the protocol operation Function DISABLED N/A [DISABLED – ENABLED]
Listening TCP port in the relay TCP Port 2404 N/A [0 : 65535]
Address in the ASDU header
Common Addr of
ASDU
255 N/A [0 : 65535]
Number of seconds for instantaneous
me
tering
Cyclic Meter Period 0 1 s [0 : 3600]
Synchronization Event Synchronization Event
0
0 N/
A
[0 : 3600]
1st Octect of IP address of 104 master 1
IEC104 NET1 CLI1
OCTET1
0 N/A [0 : 255]
2nd Octect of IP address of 104 master 1
IEC104 NET1 CLI1
OCTET2
0 N/A [0 : 255]
3nd Octect of IP address of 104 master 1
IEC104 NET1 CLI1
OCTET3
0 N/A [0 : 255]
4th Octect of IP address of 104 master 1
IEC104 NET1 CLI1
OCTET4
0 N/A [0 : 255]
1st Octect of IP address of 104 master 2
IEC104 NET1 CLI2
OCTET1
0 N/A [0 : 255]
2nd Octect of IP address of 104 master 2
IEC104 NET1 CLI2
OCTET2
0 N/A [0 : 255]
3nd Octect of IP address of 104 master 2
IEC104 NET1 CLI2
OCTET3
0 N/A [0 : 255]
4th Octect of IP address of 104 master 2
IEC104 NET1 CLI2
OCTET4
0 N/A [0 : 255]
Enable or disable the protocol operation
Function 2 DISABLED N/A
Listening TCP port in the relay
TCP Port 2 2404 N/A [0 : 65535]
Address in the ASDU header
Common Addr of
ASDU 2
255 N/A [0 : 65535]
1st Octect of IP address of 104 master 1
IEC104 NET2 CLI1
OCTET1
0 N/A [0 : 255]
2nd Octect of IP address of 104 master 1
IEC104 NET2 CLI1
OCTET2
0 N/A [0 : 255]
