I-6 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.1 FACTORY DEFAULT SETTINGS APPENDIX I: FACTORY DEFAULT CONFIGURATION
Product Setup > Communication Settings > IEC 870-5-104 (CONT.)
Setting Description Name Default Value Step Range
User
Value
3nd Octect of IP address of 104 master 1
IEC104 NET2 CLI1
OCTET3
0 N/A [0 : 255]
4th Octect of IP address of 104 master 1
IEC104 NET2 CLI1
OCTET4
0 N/A [0 : 255]
1st Octect of IP address of 104 master 2
IEC104 NET2 CLI2
OCTET1
0 N/A [0 : 255]
2nd Octect of IP address of 104 master 2
IEC104 NET2 CLI2
OCTET2
0 N/A [0 : 255]
3nd Octect of IP address of 104 master 2
IEC104 NET2 CLI2
OCTET3
0 N/A [0 : 255]
4th Octect of IP address of 104 master 2
IEC104 NET2 CLI2
OCTET4
0 N/A [0 : 255]
IEC104 SCALE CURRENT IEC104 SCALE
CU
RRENT
1 [0,00001; 0,0001; 0,001;
0,01; 0,1; 1; 10; 100; 1000;
10000]
IEC104 SCALE VOLTAGE IEC104 SCALE
VOLTAGE
1
IEC104 SCALE POWER IEC104 SCALE
POWE
R
1
IEC104 SCALE ENERGY IEC104 SCALE
ENERGY
1
IEC104 SCALE OTHER IEC104 SCALE
OT
HER
1
IEC104 DEADBAND CURRENT IEC104 DEADBAND
CU
RRENT
30000 [0 : 65535]
IEC104 DEADBAND VOLTAGE IEC104 DEADBAND
VOLTAGE
30000 [0 : 65535]
IEC104 DEADBAND POWER IEC104 DEADBAND
POWE
R
30000 [0 : 65535]
IEC104 DEADBAND ENERGY IEC104 DEADBAND
ENERGY
30000 [0 : 65535]
IEC104 DEADBAND OTHER IEC104 DEADBAND
OT
HER
30000 [0 : 65535]
IEC104 IOA BINARIES IEC104 IOA
BINARIES
1000 [0 : 65535]
IEC104 IOA DOUBLE POINTS IEC104 IOA DOUBLE
POINTS
1500 [0 : 65535]
IEC104 IOA ANALOGS IEC104 IOA
ANALOGS
2000 [0 : 65535]
IEC104 IOA COUNTERS IEC104 IOA
COUNT
ERS
4000 [0 : 65535]
IEC104 IOA COMMANDS IEC104 IOA
COMMANDS
3000 [0 : 65535]
IEC104 IOA ANALOG PARAMETERS IEC104 IOA ANALOG
PARAMETERS
5000 [0 : 65535]
IEC 870-5-104 Notes
Note 1: Cyclic Meter Period 0 value means no spontaneous metering
